Beskrivning
Frame:
Mondraker SCREE 6061 Alloy Stealth Evo, Updated Zero Suspension System, 130mm travel, Forward Geometry, internal removable battery, Boost 12x148mm rear axle, UDH, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.
Sizes:
S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm
Rear shock:
RockShox Deluxe Select DebonAir, 165x45mm. Settings: Low-speed rebound, air preload. Trunnion top mount, 30x8mm bottom bushings
Shock settings:
C37 compression, R85 rebound, 4 Tokens
Fork:
RockShox Psylo Silver 29, 150mm, Motion control damper, Solo Air, tapered steerer tube, Boost 15x110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload
Headset:
Acros custom ZS56/ZS56, 1-1/8″, 1.5″ head tube, Internal cable routing, sealing plugs without blocklock
Stem:
Onoff S6 30mm 0º, 6061 forged alloy + CNC, 31.8mm barbore
Handlebar:
Onoff S6 1.0 7050 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 38mm rise.
Grips:
Onoff Desert Pro, CNC lock-on, 135mm. L and XL: Thicker size
Seatpost:
X-Fusion Manic diameter 31.6mm,1X Remote lever, S size: 361x125mm, M size: 425x150mm, ML size: 469x170mm, L size: 521x190mm, XL size: 531×200
Saddle:
Ergon SMC10 Gel
Front brake:
Sram DB6, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
Rear brake:
Sram DB6, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads
Brake lever:
Sram DB6, tool reach adjust, lever pivot bushings
Rims:
WTB Sportterra Tough,6061 Welded Aluminum, 30mm internal width, tubeless ready, 28 spokes
Spokes:
WTB Straight gauge spokes & black brass locking nipples
Front hub:
WTB Frequenzy Sport Boost 15x110mm, fully machined aluminum, IS 6 bolts
Rear hub:
WTB Frequenzy Sport Boost 12x148mm, fully machined aluminum, IS 6 bolts, HG freehub
Front tire:
Maxxis Dissector 29×2.6, tubeless ready, tubeless ready, 3C MaxxTerra compoundm EXO+ protection, 60TPI, folding bead
Rear tire:
Maxxis Dissector 29×2.6, tubeless ready, tubeless ready, 3C MaxxTerra compoundm EXO+ protection, 60TPI, folding bead
Crankset:
E.13 Helix Core E*Spec Plus, All sizes: 160mm
Rings:
Sram Eagle 34T T-Type, direct mount, steel, CL55
Chain:
Sram 70 T-Type, 12s Flattop, PowerLock
Rear derrailleur:
Sram 70 Eagle, T-Type, 12s
Shift levers:
Sram Trigger 70, 12s, T-Type Actuation
Casette:
Sram XS-1270, 10-52T, 12s
Weight:
25,8 kg
Display:
Kiox 400C / Bosch Mini Remote
Motor:
Bosch Performance Line CX (25Km/h) SMART SYSTEM (BDU384Y)
Battery:
Bosch Powertube 800Wh
